Yanzeo SU990 Android 13 Honeywell N5703 Rugged PDA Scanner 13 Keys IP66 Meter-Reading PDA Optional UHF RFID/LF/Fingerprint
- Model
- SU990
Review
Description
Key Features
Hybrid Touchscreen & Physical Keypad Design
Equipped with a vivid 5.0-inch IPS HD display (>450 cd/m² brightness) and 13 ergonomic soft silicone keys, the SU990 allows field workers and warehouse operators to navigate complex apps easily while executing rapid numeric entry, scanning, and confirmations—even when wearing thick gloves or operating in wet environments.
Advanced Android 13 Platform & High-Efficiency Processing
Running on clean, modern Android 13 with an Octa-core 64-bit processor and 4GB RAM + 64GB storage, the SU990 ensures smooth multitasking across enterprise ERP, WMS, and inventory management software, with complete support for custom Android APK deployments.
Enterprise-Grade Barcode Scanning Engines
Equipped with industry-leading imaging sensors (including genuine Honeywell N6703 / N5703 / N6602-W2 2D imagers or Mingde/Honeywell 1D laser engines), the SU990 reads damaged, wrinkled, poorly printed, and on-screen barcodes instantly with point-and-shoot simplicity.
Broad Modular Capabilities: UHF / LF / Meter-Reading Infrared / Biometrics
Going far beyond standard market alternatives:
UHF RFID: High-gain module supporting 840–960 MHz with a read range exceeding 1.5 meters for rapid tag inventory.
LF RFID: 125K / 134.2K support for livestock, access control, and specialized asset management.
Meter-Reading Infrared: 38kHz / 940nm optical infrared interface for electrical, water, and gas meter data collection.
Fingerprint Sensor: High-security biometric reader with AES/DES encryption for secure authentication and field law enforcement.
Rugged IP66 Housing with Full-Shift 4800mAh Battery
Certified with IP66 dustproof and waterproof ratings and tested to survive repeated 1.5-meter drops onto concrete, the SU990 thrives in dusty warehouses, rainy outdoor fields, and cold storage (-20°C to 55°C). The 4800mAh rechargeable polymer battery provides continuous power for full 10-12 hour work shifts.
Technical Specifications
Category | Specification Details |
|---|---|
Brand & Model | Yanzeo SU990 |
Operating System | Android 13.0 |
Google Services | Full GMS (Google Mobile Services) |
Processor (CPU) | MT6765X Octa-Core 64-Bit High-Performance Processor |
Memory (RAM + ROM) | 4GB RAM + 64GB ROM (MicroSD / TF Card Expansion up to 128GB) |
Display | 5.0-inch IPS Touch Screen, 720 × 1280 HD Resolution, Brightness > 450 cd/m² |
Keypad | 13 Functional Soft Silicone Keys (Numeric / Navigation / Scan Triggers) |
Cellular Network | 4G LTE Full Netcom (Multi-band global connectivity) |
Wi-Fi | Dual-band 2.4GHz / 5GHz, IEEE 802.11 a/b/g/n/ac |
Bluetooth | Bluetooth 5.0 (Transmission Range: 5–10 meters) |
GNSS / Positioning | GPS, GLONASS, Galileo, BeiDou (BDS) |
Interface / Ports | Type-C USB × 1 (Supports OTG), POGO Pin × 1 |
Card Slots | PSAM Slot × 2, Micro SIM Slot × 1, TF Card Slot × 1 |
Camera | Rear 8.0MP Autofocus Camera with Flash (Optional upgrade to 13.0MP) |
Battery Capacity | Rechargeable Li-Polymer 3.7V / 4800mAh Battery |
Industrial Sealing | IP66 (Dustproof and Water Resistant) |
Drop Specification | Withstands multiple 1.5m drops to concrete across operating temperature |
Operating Temperature | -20°C to +55°C (-4°F to 131°F) |
Storage Temperature | -40°C to +70°C (-40°F to 158°F) |
Dimensions & Weight | 178mm (L) × 78mm (W) × 24mm (H) |
Standard 1D Barcode (Optional) | Mingde SE966 / Honeywell N4313 |
Standard 2D Barcode (Optional) | Honeywell N5703 / N6703 / N6602-W2 High-Precision 2D Imager |
NFC (Standard/Optional) | 13.56 MHz, ISO14443A/B, ISO15693 protocols, Read range: 2–5 cm |
UHF RFID (Optional) | 840–960 MHz (EPC C1G2 / ISO18000-6C), Read range: > 1.5 meters |
LF RFID (Optional) | 125KHz / 134.2KHz (Animal & Industrial Tag Identification) |
Infrared Module (Optional) | 38kHz Operating Frequency, 940nm Wavelength, Communication Range > 4m (Meter-Reading) |
Fingerprint Sensor (Optional) | 11.3 × 12.4 mm sensor area, supports AES and DES hardware encryption |
ID Card Module (Optional) | 13.56MHz ± 7kHz, reading distance 0–5cm |
Application Scenarios
Warehouse & Logistics: Inventory cycle counts, cross-docking, picking, packing, and sorting.
Utility & Power Grid: Electricity, gas, and water meter reading via direct 38kHz infrared port.
Retail & Store Operations: Price verification, stock intake, shelf replenishment, and mobile POS.
Manufacturing & Asset Tracking: Work-in-progress (WIP) tracking, tool crib management, and UHF asset auditing.
Field Service & Inspection: Route delivery, proof of delivery (POD), security rounds, and identity verification.
