UHF RFID Reader| Yanzeo R784| Long Range 8m Outdoor IP67 9dbi Antenna UHF Integrated Reader RJ45 USB RS232 RS285 RS485 For Access Management
- Model
- Yanzeo R784
Item specifics
- Brand
- Yanzeo
- Model
- R784
Review
Description
UHF RFID Reader| Yanzeo R784| Long Range 8m Outdoor IP67 9dbi Antenna UHF Integrated Reader RJ45 USB RS232 RS285 RS485 For Access Management
- Product specification
- l Support ISO18000-6C (EPC GEN2) international standards;
- l Integrated structure design, beautiful appearance, suitable for outdoor environment;
- l Integrate high-performance linear polarized antennas, Recognize the long range distance stably;
- l Supports tag echo signal detection, tag data filtering, clock stamping, and input and output functions;
- l Recognition speed is fast, and the identification of single label can reach 140 times/second;
- l Adopt frequency hopping working mode, strong anti-interference ability and high recognition sensitivity;
- l Support development in multiple languages, such as VC, VB, C, etc.
- l Supports online upgrades, has a rich communication interface, and can be customized to the needs of users.
Application
- l Warehouse Management
- l Supply Chain Management
- l Vehicle Management
- l Line Management
- l Source Management
- l Asset Management
- l Personnel Management
- l Attendance Management
- l Product Anti-counterfeiting Management
| model | R783/R784-9DB |
|---|---|
| Supported protocols | ISO18000-6C（EPC GEN2） |
| working frequency | ISM 902～928MHz and ISM 865～868MHz，Other frequency standards (customized) |
| Operation mode | FHSS |
| RF power | 0~30dBm，Software Programmable |
| Reading speed | Single card average reading is 64bits, less than 6ms, Software Programmable |
| Work mode | reading Active and reading passive, Software Programmable |
| Communication Ports | N:Wiegand26/34/98, RS232/RS485,USB E:Wiegand26/34/98, RS232/RS485,TCP ,USB |
| Input interface | 1 way trigger input |
| Reading range | 0-6 m(High power 0~10m) |
| Status indicators | buzzer |
| Antenna | 9dbi circular polarization antenna |
| Power supply | DC＋7~12V |
| Size | 257mm×257mm×42mm |
| Weight | 1.45 Kg（Package:2.45kg） |
| Operation Temp | -20℃~+70℃ |
