Model
Yanzeo SR40

Item specifics

System Parameter:
ARM7+UHF model
Read Range:
>2m
Group of reading performance:
>50pcs
Support Protocol:
Fixed Frequency Band and FHSS Software Programmabl
Operating Mode:
0-30dBm(Adjustable)
Output Power:
2dBi circular polarize antenna (Integrated)
Antenna:
Fixed Frequency Band and FHSS Software Programmabl
Communication Port:
RS485、Wiegand26、Wiegand34
Power:
+12V
Power Consumption:
< 1W
Operation:
-20℃ ~ +70℃(Customized)
Humidity:
20% ~ 95%(without condensation)
Storage:
-40℃ ~ +125℃

Review

Description

Yanzeo SR40 UHF RFID Reader Access Control Integration
Product description



Yanzeo SR40 is a High Performance UHF integrated reader for long range operation. The reader operates in frequency range of 860MHz~960MHz design to read ISO18000‐6C and ISO18000‐6B protocol ID Tag.The reader can be widely applied in many RFID application systems such as logistics, access control, and anti-counterfeit and industrial production process control system.

packaging

behind

Accessories

packaging

Long-distance Integrated Reader – 860~960MHz


Mainly used in business,payment,health care,tobacco,some industries,etc.

Technical Specification

ITEMS

DESCRIPTION

Model:

SR40

System Parameter:

ARM7+UHF model

Operating Frequency:

International(920~925MHz)

USA(902~928MHz)

EUR(865~868MHz)

Others(Customized Tag)

Read Range:

2m(Read and write distance varies by different tags)

Group of reading performance:

>50pcs

Support Protocol:

Fixed Frequency Band and FHSS Software Programmable;

Frequency Hopping  Mode:

Master‐Slave Mode(Online Mode)、Time Scheduled Modes、Trigger Mode

Operating Mode:

0-30dBm(Adjustable)

Output Power:

  4dBi circular polarize antenna (Integrated)

Antenna:

Fixed Frequency Band and FHSS Software Programmable;

Communication Port:

RS485、Wiegand26、Wiegand34、RJ45、WIFI

Power:

+12V

Prompt:

Beep or LED light flash

Beep or LED light flash

< 1W

OPERATING ENVIRONMENT

Operation:

20℃ ~ +70℃(Customized)

Humidity:

20% ~ 95%(without condensation)

Storage:

40℃ ~ +125℃

PHYSICAL PARAMETER

Dimension:

160x130x21MM

Net Weight:

250G

Weight:

350G

ACCESSORES

Software Pack

(Optional):

API Software Development Kits complete with VB,C#Sample Program

Long-distance Integrated Reader – 860~960MHz


Specification

ITEM

DESCRIPTION

RED

+12V

BLACK

GND

GRAY

TRIGGER

PURPLE

RS485 R-

ORANGE

RS485 R+

GREEN

DATD0

WHITE

DATD1

Area of Application
